2 Channel DVR 12v 1080p AHD

The F4 series Mobile Digital Video Recorder (MDVR) is a cost-effective and highly expandable product developed for in-vehicle video surveillance and remote video monitoring. Among its offerings, the 2 Channel DVR 12v 1080p AHD has been a best-selling product in 2023. Utilizing the Linux operating system, it incorporates cutting-edge technologies such as H.264/H.265 video compression/decompression, 4G network connectivity, and GPS real-time positioning.

2 Channel DVR 12v 1080p AHD

The MDVR is capable of recording video at resolutions of 1080P, 720P, and D1, providing comprehensive recording of driving information and remote video uploads. When used in conjunction with fleet tracking management software, it enables real-time monitoring, remote video information processing, intelligent vehicle scheduling management, and playback analysis based on a central database.

The product boasts strong shock resistance, a sleek appearance, flexible and convenient installation, comprehensive functionality, and high reliability. It is suitable for various applications in the field of mobile surveillance, including law enforcement, financial escort, long-distance passenger transport, logistics, emergency response teams, and more.

Main Features of 2 Channel DVR 12v 1080p AHD

4G, GPS/BD, WIFI, SD card, ADAS (Advanced Driver Assistance Systems), DSM (Driver Status Monitoring), BSD (Blind Spot Detection), Passenger Counting.

Specifications of 2 Channel DVR


Detailed Specification

Appearance structure

Size: 145×58×193mm

Shell material: PC+ABS, body material: aluminum alloy

Protection grade


Environmental suitability

Operating temperature: -30℃~70℃,

Storage temperature: -40℃~85℃

Working voltage

Working voltage range: 9 - 32V

Support car battery protection: 8.5V±0.5V/12V system, 17V±0.5V/24V system

12V/24V adaptive,36V system is not supported

Ultra-low power consumption design

Static current <2mA

Support zero- power-consumption sleep mode

Power consumption

Average power consumption is less than 30W

Super capacitor

3 super capacitors can supply power to the system and camera

2~3s to save the complete video before power failure

Indicator lights

4 lights (1 positioning signal, 1 communication signal, 1 video recording, 1 terminal operation indication)

External interface

Power supply: TE-1318384-2

Positioning antenna connector: Fakra-C blue

Communication antenna connector: Fakra-D

Video interface: M12-4

IPC interface: M12-6


Maximum 6 channels of AHD/CVBS video input, can supply power to the camera, the output voltage value is 12V, single channel maximum output current 0.5A

1-channel IPC video input connector, 12V power supply

1-channel CVBS output


2-way camera recording, recording line supports key input detection

1 way shout MIC input


2.5-inch mechanical / solid state hard disk, can support 7mm / 9.5mm, hard disk shock absorption device fixed in the terminal (Maximum capacity support 2TB)

2 SD cards, pluggable mode, does not support simultaneous recording (Maximum capacity support 512GB)

Data interface

2-way RS232 interface, 5V power supply @ 500mA

1-way 485 interface, 1 way IPC interface, 12V power output (1A)

Positioning module

GPS and BeiDou positioning module

Communication module

4G module

SIM card

Drawer plug-in SIM card

IO function

8-channel input: ACC, left steering, right steering, door edge, emergency, reverse, brake, speed pulse

1 way output: fuel break power
