What is a Mobile NVR?


A mobile NVR, or Network Video Recorder, is a type of device used in vehicle surveillance systems. It is primarily designed to store and manage video data and other information captured by cameras and monitoring devices installed on vehicles. This technology is commonly utilized in locations such as public buses, trucks, small vehicles (taxis), and is also employed by law enforcement agencies and public transportation services.

Mobile NVR

Mobile NVR Function:

GPS positioning:

- Records vehicle location, speed, direction, and other information

- Synchronously saves data with video recordings


BDS positioning:

- Satellite navigation system developed by China

- Provides positioning, navigation, and time services globally


CAN Data Collection:

- Acquires vehicle and engine telematics data


Video:

- Supports H265/H264 video format

- 6 channel AHD video input


Storage:

- Supports 2.5-inch mechanical/solid-state drive

- 2*SD card slots for pluggable storage


Cloud storage:

- Capable of storing hours of footage

- Options to stream or download videos


Alarm:

- Various alarm functions available: emergency, parking timeout, overspeed, line deviation, power failure, low power, GPS fault, GPS/4G antenna open/short circuit, etc.


Vehicle monitoring:

- Automatic monitoring and positioning function

- Geo-fence function for virtual boundaries

- Mileage statistics, blind spot reporting, trajectory storage, etc.


Voice calls:

- Supports call and remote monitoring functions

- TTS text and voice broadcasting functions

Item

Detailed Specification

Appearance structure

Size: 145×58×193mm

Shell material: PC+ABS, body material: aluminum alloy

Protection grade

IP54

Environmental suitability

Operating temperature: -30℃70℃,

Storage temperature: -40℃85℃

Working voltage

Working voltage range: 9 - 32V

Support car battery protection: 8.5V±0.5V/12V system, 17V±0.5V/24V system

12V/24V adaptive36V system is not supported

Ultra-low power consumption design

Static current <2mA

Support zero- power-consumption sleep mode

Power consumption

Average power consumption is less than 30W

Super capacitor

3 super capacitors can supply power to the system and camera

2~3s to save the complete video before power failure

Indicator lights

lights (1 positioning signal, 1 communication signal, 1 video recording, 1 terminal operation indication)

External interface

Power supply: TE-1318384-2

Positioning antenna connector: Fakra-C blue

Communication antenna connector: Fakra-D

Video interface: M12-4

IPC interface: M12-6

Video

Maximum 6 channels of AHD/CVBS video input, can supply power to the camera, the output voltage value is 12V, single channel maximum output current 0.5A

1-channel IPC video input connector, 12V power supply

1-channel CVBS output

Audio

2-way camera recording, recording line supports key input detection

1 way shout MIC input

Storage

2.5-inch mechanical / solid state hard disk, can support 7mm / 9.5mm, hard disk shock absorption device fixed in the terminal (Maximum capacity support 2TB)

2 SD cards, pluggable mode, does not support simultaneous recording (Maximum capacity support 512GB)

Data interface

2-way RS232 interface, 5V power supply @ 500mA

1-way 485 interface, 1 way IPC interface, 12V power output (1A)

Positioning module

GPS and BeiDou positioning module

Communication module

4G module

SIM card

Drawer plug-in SIM card

IO function

8-channel input: ACC, left steering, right steering, door edge, emergency, reverse, brake, speed pulse

1 way output: fuel break power

YUWEI is a manufacturer and supplier of vehicle monitoring equipment. Our factory is located in Guangdong, China, covering an area of 15,000 square meters. We have more than 500 employees, including 180 research and development personnel. We welcome fleet managers to visit and explore opportunities for cooperation.


Email:hello@yuweitek.com

What are the main functions of MNVR?

The main functions of MNVR include video recording, storage, remote access, GPS positioning, and alarm monitoring. It helps users achieve real-time monitoring and tracking of vehicles, as well as record critical data for subsequent analysis.

What types of cameras does MNVR support?

MNVR typically supports various types of cameras, including analog cameras, digital cameras, AHD cameras, etc., to meet different user requirements.

How does MNVR store data?

MNVR usually employs methods such as solid-state drives, SD cards, and cloud storage for data storage, ensuring the security and stability of video data.
