Fleet Dash Cam with GPS and HD cameras

Model V5
The Intelligent Video Telematics V5 is a feature-rich 4G Dash Camera designed forthe car video surveillance industry.

lt is a dash cam front and rear . supports up to 4 channel cameras, offers real-time audio and video recording, andutilizes dual TF cards for storage. With Global 4G network connectivity, it enables livevideo transmission, while GPS/BDS positioning ensures accurate tracking.

The dashboard camera V5 also integrates built-in active safety algorithms (ADAS, DSM) for enhanced se-curity. Widely used in online car-hailing, taxis, logistics, and official vehicles.

Product Features

Function Description

Specification parameters

Product Features
Dash Cam with GPS
Dash Cam with GPS

Built-in positioning module and antenna, support GPS/BDS dual mode positioning.

Built-in communication module and antenna, support Global 4G communication, support SMS command function.

Terminal has ultra-clear real-time video recording, integrate 1-channel 1080P high-definition camera, and can be externally connected to 3-channel 720P high-definition cameras.

Maximum support 2*2TB TF card, which can store real-time video.

Support ADAS (advanced driver assistance system), DSM (driver status monitoring) functions.

Support face recognition, non-mask recognition and people counting functions.

Have 1 USB interface, support driving record export function.

Function Description
Fleet Tracking Management

Suitable for online car, cab, city distribution logistics vehicles, official vehicles and other industries.

Vehicle monitoring
Vehicle monitoring
Support JT/T808 communication protocol, has position reporting function, trajectory storage function, base station assisted positioning function, parameters query and setting functions which include license plate, report interval, and overspeed threshold etc.
1080p Vdeo
1080p Vdeo
Using JT/T1078 video protocol, support real-time video playback, remote historical video playback and download, recording video after flameout function. Supports up to 4-channel of video capture, which can clearly capture the picture in front of the vehicle, the front and rear rows of the car, and the driver's status picture. Ultra-clear real-time video recording, support AHD1080P, 720P high-definition camera.
Storage
Storage
It uses dual TF card to store video circularly, special encrypted file format, and the video data can be overlayed with information such as vehicle brand, location, longitude and latitude, vehicle speed, time, and channel number. Support remote search and upload of video information through the platform. Data store use first-in, first-out manner.
Alarm
Alarm
Support overspeed alarm, timeout alarm, Geo-fence alarm, emergency alarm, camera failure alarm, storage medium failure alarm detection and uploading to platform.
Voice
Voice
TTS text and voice broadcast function. Support overspeed voice prompts, TF card insertion and removal voice prompts, active security alarms and other voice prompts.
Remote maintenance
Remote maintenance
Support OTA remote upgrade function. Support remote debugging command to setting and query parameters by WeChat mini program.
Intercom
Intercom
Two-way intercom function, G711A audio format.
Intelligent algorithm
Intelligent algorithm
Support FaceID, support driver check-in by FaceID. People counting: The number of people in the car is calculated and reported through the algorithm of the in-vehicle camera. Recognition of not wearing mask: The terminal can detect whether the driver wear mask. If not wearing a mask, it will generate a voice prompt and report an alarm to the platform.
Specification parameters

Parameter classification

Parameter item

Details

Remark

Basic parameters

Appearance

device integrate with ADAS cam


Product Type

4G DVR Car Video Terminal


network standard

4G Global Band


Memory

256MB(Flash)+1GB(DDR)


Front camera

(ADAS Camera)

1080P, MIPI Camera, H:112°V:55°


In-car camera

AHD 720P, with light sensor/infrared night vision,


DSM camera

AHD Camera, single pass, infrared night vision, H=60° V=42°


4th Channel camera

AHD 720P


Hardware function









GPS

Support: GPS+BDS


Wi-Fi

802.11b/g/n


trumpet

8 ohms 1.5 watts, 1 channel, with sound cavity


MIC

Built-in dual silicon microphone design


Accelerometer

3-axis accelerometer


Interface

micro 5Pin USB

USB×1, data interface


BMW connector

Power+/GND

ACC

Left turning signal cable

Right turning signal cable

SOS Cable (Panic button)


RS232

1*RS232


SIM card holder

Micro SIM


TF card holder

TF×2 (Card 1 and Card 2 support circular storage)


Power supply

Power supply

12V/24V power supply


Button&

Indicator light



Reset button

Long press the power button for 8 seconds to reset


indicator light

2-color indicator


Alarm key

Standard emergency alarm connector




Antenna



GPS Antenna

Built-in ceramic antenna


4G antenna

Built-in FPC+IPEX transposon


WIFI antenna

Built-in FPC+IPEX transposon


Memory card

4G2TB, patented DXR streaming storage format


Electrical Specification

Operating temp.

-20℃70℃


Storage temp.

-40℃85℃


Static Protection

6KV contact, 10KV air


Vibration test

Car vibration


Current consumption

When the working voltage is 12V, the current is from 500mA to 1A (depending on whether the algorithm is turned on, etc.)

When ACC OFF: ≤3mA


Other quality requirements

According to JT/T794 standard (including hard test, soft test, reliability, quality, etc.)


Product specification pictures:

hnweb_Fleet <a href='https://en.yuweitek.com/fleet-dash-cam.html' style='color: #014a97;' target='_blank'>Dash Cam with GPS</a> and HD cameras

Fleet Dash Cam with GPS and HD cameras

Red light

Equipment situation

Light status

Before the program is ready

Solid on

during upgrade

On for 1 second, off for 4 seconds

update completed

\

camera lost

On for 0.1 seconds, off for 0.1 seconds, flashing 4 times at a time, flashing once every 4 seconds

SIM card missed

On for 1 second, off for 1 second

other status

Always off



Green light

Equipment situation

light status

Before the program is ready

Solid on

during upgrade

On for 1 second, off for 4 seconds

update completed

\

The card is recording normally

On for 1 second, off for 1 second

Unrecorded card abnormal

On for 0.1 seconds, off for 0.1 seconds, flashing 4 times at a time, flashing once every 4 seconds

other status

Always bright

TF card/SIM card/USB location

Fleet Dash Cam with GPS and HD cameras


Related Questions and Answers

Are fleet dash cams legal?

Fleet dash cams are legal in most regions, but specific regulations vary by country. Some areas may have specific requirements for the use and data protection of the dash cam. It is recommended to consult with the relevant local agencies before installation and abide by relevant regulations.


What data does the fleet dash cam record?

The car dash cam can record video, sound, driving speed, GPS position, time and other information in and around the car. Some advanced models can also record vehicle acceleration, steering angle, mileage, fuel consumption, driver status and other data. This data can be used to monitor driving habits, identify causes of accidents, improve route planning, and more.


How do fleet dash cams work?

Fleet dash cams are usually installed inside vehicles and collect driving data through cameras and other sensors. They record video, sound, GPS location, vehicle speed, and more and store it on the device or in the cloud. These data can be used to analyze driving behavior, map driving paths, replay accidents, and more.

Can a dash cam work at night or in low light conditions?

Yes. Our dash cam supports continuous work at night and other conditions, and maintains a clear picture;

Will fleet dash cams work in areas without cellular signal or Wi-Fi?

Yes. When the car is in limited or no cellular coverage, the dash cam will buffer the footage of the incident on the dash cam. Once the connection is restored, the video will be sent to the platform and available for viewing. (The local storage is limited, if the memory is exceeded, the previously stored video will be overwritten. If an accident occurs, the accident video will be selected first to keep the storage)

Can I request dashcam video clips for a specific date and time?

Yes. As long as there are available materials on your SD card, you can read the SD card or manage the background to get the video and edit the video.

What events will trigger the AI fleet dashcam to record?

The AI dash cam starts recording immediately after the vehicle is started and will continuously record video footage to the SD card of the fleet dash cam.

How much does a dash cam front and rear cost?

Different models mean different configurations of dash cam (specifically reflected in camera video quality, storage capacity, display size, auxiliary functions, etc.). The cost of a single YUWEI car camera is US$20; for example, the price of Mobile DVR is US$120


*It is recommended that you can send us your functional requirements and request a quotation from us. We are a Chinese automobile monitoring manufacturer, and cost is our biggest advantage;

Fleet dash cam solution

You can refer to "Fleet Management Solutions" to understand the management system solutions of yuweitek trucks, buses, school buses, buses, taxis and other fleets.

https://en.yuweitek.com/solution.html

Does the dash cam record video when your car is not running?

When the car is parked or turned off, the AI car camera stays alert and can continue to help your car work safely in low power mode. The onboard camera will "wake up" to record a triggering event, such as detected motion.

Why are fleets using commercial dash cams?

Accidents involving commercial vehicles are becoming more frequent and insurance claims are a time-consuming issue for both drivers and fleet managers. The lack of hard evidence often means companies are automatically liable for false claims, money grabs and losses that currently cost businesses millions of dollars each year.



Yuwei's commercial dash cam is a compact combination camera and recording system that provides evidence in the event of a vehicle accident. These palm-sized devices easily attach to windshields to record the road ahead.

Which fleets are dash cams suitable for?

Trucks, school buses, buses, passenger cars, sanitation vehicles, online car-hailing, taxis, muck trucks, fire trucks, etc.
