AI Dash Cam with ADAS and DSM

V8N
The Intelligent Dash Cam V8N is a 4G dash cam that integrates high-definition video recording functionality. This device features a front and rear dual-camera integrated design, providing comprehensive real-time monitoring of both the interior and exterior environments of the vehicle. It supports built-in active safety algorithms that can detect dangerous driving events and unsafe driving behaviors. The system provides real-time voice alerts to the driver to avoid collisions and accidents and reports incidents to the customer management platform, facilitating the statistical analysis of driver behavior. It supports uploading real-time vehicle location information and historical trajectories to the customer management platform, offering high-definition real-time video and historical video viewing, making management more convenient and efficient.

Product Features

Function Description

Specification parameters

Product Features
AI DASH CAM

Built-in 4G communication module, Wi-Fi module, GNSS module.

Integrated starlight-grade wide dynamic front camera (HFOV: 106°; DFOV: 139°), supporting 1080P HD recording.

Integrated 2-megapixel IR-CUT infrared ultra-wide-angle interior camera (HFOV: 152°; DFOV: 180°), supporting 720P recording.

Both built-in dual cameras offer adjustable angles, providing a more flexible and versatile user experience.

Supports up to 4-channel (including 2 channels from the main unit) video recording.

Supports external monitors for real-time video content viewing.

Dual TF card support, with each TF card supporting up to 2TB capacity.

Supports ADAS functions: lane departure warning (LDW), headway monitoring and warning (HMW), forward collision warning (FCW), pedestrian collision warning (PCW).

Supports DMS functionality, detecting unsafe driving behaviors.

AI DASH CAM WITH ADAS

Facial recognition support for effective driver supervision.

Extended camera supports BSD functionality, monitoring pedestrians or non-motorized vehicles within the driver's blind spot.

Supports aggressive driving detection, including sudden acceleration, sudden deceleration, and sharp turns.

Supports two ultra-low power modes (2mA/5mA) for instant device response.

Built-in USB interface for portable storage device video export, enabling convenient data transfer.

Equipped with CAN bus for real-time vehicle data collection.

Supports mobile app for function settings, video playback, downloads, real-time streaming, and historical trajectory queries.

Easy installation with a compact design that does not obstruct the driver's view.

Function Description

AI Features

The V8N supports ADAS, DMS, facial recognition, BSD, and aggressive driving detection, providing comprehensive monitoring of both vehicle and driver behavior. It uses voice alerts to remind the driver to drive safely in real-time and uploads events and alarm attachments to the platform.


*Warning: AI functions must be calibrated and configured strictly according to the installation and operation instructions; otherwise, the AI functions will not work properly.


ADAS

AI DASH CAM WITH ADAS


PCW

AI DASH CAM WITH PCW

DMS


Facial Recognition

Facial Recognition DASH CAM

BSD

DASH CAM WITH BSD

Aggressive-Driving

Aggressive-Driving

Warning tone

Function

Alarm Type

Voice prompts

ADAS

Lane Departure

Lane Departure


“ DiDi”

Vehicle distance monitoring

Keep Your Distance

Front vehicle collision

Caution Collision

Camera occlusion

Camera Obstructed

PCW

Pedestrian collision

Caution Pedestrian

Zebra crossing warning

Attention. Pedestrian Crosswalk

Front vehicle starts

Front Car Start

DMS

Yawning

Caution Fatigue

Close your eyes

Caution Fatigue

Distraction

Caution Distraction

Make phone calls

Mobile Phone Detected

smokes

Smoking Detected

Infrared glasses blocking

Please Wear Suit Glasses

Not wearing seat belts

No Seatbelt Detected

Driver abnormality

Driver Abnormally

Camera occlusion

Camera Obstructed

Face Recognition

Face Recognition

successful Successful Authentication, Happy Driving

Authentication Failed

BSD

Blind spot monitoring

Please pay attention to blind spot surveillance

Aggressive driving

Rapid acceleration

Harsh Acceleration

Rapid deceleration

Hard Braking

Sharp Turn

sharp turn

* Note: The specific prompt tone is subject to the actual broadcast content of the product


Specification parameters

Product model: V8N

system

Embedded Linux

4G

LTE-FDD: B1/ 3/ 5/ 7/ 8/ 20/ 28

LTE - TDD : B38/ 40/ 41

WCDMA : B1/ 5/ 8

GSM / EDGE : B3/ 8

Wi - Fi

802.11b/g/n

storage

TF storage card

l TF Card *2 (maximum supported 2 TB )

l patent DXR Stream storage format

Audio / Video

Audio and video input

l Host comes with 1 Channel Audio MIC

l common 4 Video input: 【default】

No. 1 Road: Front-facing camera built into the host; supports wide dynamic range and starlight level No. 2 Road: host built-in internal camera; with IR - CUT Infrared fill light

【Extension】

No. 3 Road: Optional, use camera AHD Standard; installed in the rear compartment or in the vehicle blind spot No. 4 Road: Optional, use camera AHD Standard; installed at the rear or side of the vehicle


Storage resolution

Maximum Capacity:

1 Channel : 1080P@25 fps

2 Channel : 720P@25 fps

3 Channel: 720P@25 fps

4 Channel: 720P@25 fps

Recommended configuration:

Main stream 1080P@15 fps ( ADAS ) + 720P@15 fps ( DMS ) + 720P@15 fps ( AHD ) + 720P@15 fps ( AHD )

Substream D1@15fps ( ADAS ) + D1@15fps ( DMS ) + D1 @15fps ( AHD ) + D1@15fps ( AHD )

Video Output

l Optional video installation cable, including 1 Channel video output

l Output Format: AHD

l Can connect to an external monitor to view real-time video

Video Encoding

Optional: H.264  and H.265

Default: H.264

Audio Coding

Optional: G.711A 、 G711U 、 G726 、 AMR

Default: G.711A

CBR/VBR

Optional: CBR and VBR

Default: CBR

Parameters of the host's built-in front-facing camera

Option 1

sensor type

IMX 335 (Sony) 500 10,000 ( 4:3 ) 1/2.8

Lenses

l Focal length: 2.9 mm

l HFOV: 106 ° ; VFOV: 77 ° ; DFOV: 139 ° ; Error : ± 5 °

Resolution

Highest support 2560*1920P

Wide dynamic range

support

Starlight

support

Option II

sensor type

SC 200 AI ( Smartsens ) 200 10,000 ( 16:9 ) 1/2.8

Lenses

l Focal length: 2.9 mm

l HFOV: 115 ° ; VFOV: 61 ° ; DFOV: 137 ° ; Error : ± 5 °

Resolution

Highest support 1920*1080P

Wide dynamic range

support

Starlight

support

third solution

sensor type

GC 2053 200 10,000 ( 16:9 ) 1/2.9

Lenses

l Focal length: 2.9 mm

l HFOV: 112 ° ; VFOV: 77 ° ; DFOV: 139 ° ; Error : ± 5 °

Resolution

Highest support 1920*1080P

Wide dynamic range

not support

Starlight

support

Parameters of the internal camera built into the host

sensor type

GC 2083 200 Ten thousand ( 16:9 ) 1/3

Lenses

l Focal length: 2.0 mm

l HFOV: 152 ° ; VFOV: 84 ° ; DFOV: 180 ° ; error :   ± 5 °

Signal-to-Noise Ratio

37 dB

Sensitivity

3240 Mv / lux.s

Resolution

Standard 1280*720P (optional 1080P )

sensor

Six-axis acceleration sensor

l Linear acceleration axis: X , Y , Z

l Angular velocity axes: Yaw , Pitch , Roll

interface

USB

micro 5 Pin USB *1

I/O

l 6 Input ( ACC , Emergency, Turn left, right, 2 Road reserved)

l Left and right turn:

(1) Configurable high input / low input valid ( through software APP Configuration)

(2) High level effective voltage: greater than 6.5V Low level effective voltage: less than 1.0V

(3)    Current: greater than 0.1 mA

(4) Protection: Pressure resistance 60V  Short circuit protection

SIM Booth

Micro SIM

TF Booth

2 indivual

RS 232

1 indivual




Button indicator light

Reset button

Press 3 Seconds reset


3 Single color indicator light


Indicator Lights

Device Icons

Light status description


online

AI DASH CAM WITH GPS


Green light: Successful launch


Light off: Not online


position

AI DASH CAM WITH ADAS


Green light: Positioning successful

Indicator Lights

Light off: Not positioned


Video

AI DASH CAM WITH DSM


Green light: Normal recording


Light off: Video recording abnormality

Alarm key function

Standard emergency alarm connector



position


GNSS

l P1311

l Support: Beidou / GPS

l Support single Beidou

Power supply related

Operating Voltage

l Original car battery: 12V/24V (adaptive)

l Operating voltage range: 8V~36V

Super capacitor

Built-in supercapacitor, the front-facing camera supports continuous recording after the host loses power 1 Second Purpose: To avoid abnormal power outages that may cause data loss and equipment damage

Power consumption

To be determined

environment

Operating temperature

-30 ℃ ~80 ℃

storage temperature

-40 ℃ ~80 ℃

Working humidity

15%~95%  Non-condensing

Storage humidity

15%~95%  Non-condensing

Protection level

IP30

size and weight

size(Length * Width * Height)

111.9 mm *67.4 mm *32.9 mm

(Only the middle part of the main unit, excluding the top mounting bracket and the inner camera below) Error: ±1 mm

weight

Net weight (main unit only ): 316g Error: ±10g

*Actual size and weight may vary due to individual product differences, manufacturing processes and testing methods.

Package Contents

Standard configuration: host, adapter cable, extension cable, emergency alarm button, installation wrench

Optional: Video installation line, AHD Camera, external monitor, OBD Connector wire

5. Product Structure Diagram

5.1  Product appearance size

AI DASH CAM SUPPLIER

AI DASH CAM CHINA


5.2  Indicator light /MIC

5.3 TF Card /SIM Card /USB Location / Button

6. Product Wiring Diagram

6.1  Cable wiring diagram

AI DASH CAM

YUWEI AI DASH CAM WITH ADAS

AI DASH CAM
dash cam with gps
