Advanced Driver Assistance System（ADAS）（Optional）
Alarm type | Explanation | Default enabling | Remark |
|
| condition |
|
Front Collision Warning（FCW） | Real time monitoring of the distance with the car ahead, can alert the driver 2.7 seconds before the expected collision to prevent rear-end collision. | speed per hour≥30km/h | Optional |
Lane Departure Warning（LDW） | Monitor the current lane markings and vehicle tracks, and raise the alarm to remind drivers to keep safe lanes when | speed per hour≥55km/h | Optional |
they are about to deviate unintentionally. |
Headway Monitoring and | Displays the distance (in seconds) of the vehicle ahead and alarms when approaching the preset danger distance. | speed per hour≥30km/h | Optional |
Warning（HMW） |
Pedestrian Collision Warning (PCW) | Recognises pedestrians ahead and detects distance, alerting the driver to avoid colliding with pedestrians in dangerous situations. | speed per hour | Optional |
<50km/h |
Zebra crossing detection | Recognises zebra crossings ahead and detects the distance, providing an early warning in dangerous situations to alert the driver to avoid colliding with pedestrians |
| Optional |
Notes:
Enabling speed can be configured according to the actual condition;
Can be used in most scenarios (except extreme weather), such as day, night, tunnel and rainy day;
Support failure alarm when ADAS is obscured ;
For more functional requirements, please contact the Official Technical Support department.
Driver status detection（DSM）（Optional）
Alarm type | Explanation | Default enabling condition | Remark |
Fatigue driving alarm | Identify the persistent eye closure status and yawn status (distinguish the degree of mild and severe) | speed per hour≥30km/h | Optional |
Distraction alarm | Identify driver’s persistent state when turn left or right, raise or lower the head | speed per hour≥30km/h | Optional |
Alarm when receiving and making calls | Recognize gestures when make a Phone Call | speed per hour≥30km/h | Optional |
Smoking alarm | Recognize smoking posture | speed per hour≥30km/h | Optional |
Departure alarm | Identify when the driver leaves his seat | speed per hour≥30km/h | Optional |
Driver change alarm | The current detection of faces is different from last time | speed per hour≥30km/h | Optional |
Failure alarm | Alarm when the camera is covered and invalid | speed per hour≥0km/h | Optional |
|
|
|
|
Alarm when Infrared glasses block monitoring | speed per hour≥0km/h | Optional |
Driver identification | Face recognition via local face database |
| Optional |
Notes:
The speed can be configured according to the actual use;
Capable of being used in most scenarios such as daytime, nighttime, tunnels, rain, etc. (except extreme weather);
Support ADAS masking failure prompt.
Video
The terminal adopts H264/H265 video compression technology, special streaming media format to achieve 4-6-way image real-time monitoring, timing recording, event recording, alarm recording function, which can support up to 6-way 720P analogue HD video capture, image resolution 720P/D1 optional. If you use H265 video compression technology, you can greatly save storage space and transmission traffic, improve the smoothness in low bandwidth situations, H265 improves compression efficiency by 20% to 50% compared with H264 in the same scene.
High-capacity storage
SD card is used to store images and videos. The capacity is determined by the
customer's choice and uses a proprietary, patented streaming file system for video and data file security in the in-vehicle environment.
Image transmission
Real-time transmission of surveillance video through 4G wireless network, dual stream transmission, rate adjustable. It can remotely capture and upload pictures according to alarm events.
Multimedia analysis
Adopting multimedia driving record analysis software, it can achieve audio and video synchronous playback, conditional playback, clip storage, licence plate overlay, geographic information and driving record overlay function, event analysis and record extraction function.
Vehicle monitoring
Vehicle automatic monitoring and positioning function, area setting, electronic fence function, GPS mileage statistics, vehicle mileage statistics, blind zone reporting function, track storage function, base station assisted positioning function.
Signal detection and control
6-channel signal input, 5V power supply control.
Alarm
Emergency Alarm, Parking Timeout Alarm, Speeding Alarm, Speeding Warning, Fatigue Driving Alarm, Deviation from Route Alarm, Power Loss, Low Battery Alarm, GPS Failure Alarm, GPS/4G Antenna Open/Short Circuit Alarm, and so on.
Vehicle driving analysis
Supports the function of analysing driving behaviour (rapid acceleration, rapid deceleration, idling, hard braking, etc.) through body data (analogue signal data).
Cloud guardian
Support remote fault diagnosis and debugging, remote automatic programme maintenance, remote parameter configuration and terminal operation statistics and other remote ‘cloud’ guarding functions. Improve the efficiency of equipment installation and maintenance, saving maintenance time and cost.
Road detection
Yaw, sectional speed limit alerts and alarms, inbound/outbound reports and station association control are realised.
Voice and Call
Remote listening function, remote intercom, voice prompter function and TTS text-to-speech broadcast function.
