HD 1080p Car Vehicle Blackbox Camera DVR

Full hd 1080p Car Vehicle Blackbox Camera DVR

Date Time: March 04, 2024
Reading volume: 196
Author: ROYIS

HD 1080p Car Vehicle Blackbox Camera DVR


   4 Channel AHD Vehicle DVR Supports Up To 128GB per SD Card, Dual SD Card Built-in GPS, WIFI Module , 1080P 4CH AHD.


full hd 1080p car vehicle blackbox camera dvr


Vehicle Blackbox Camera DVR Function

  • H.264 video compression.

  • 4CH 1080P HD AHD MDVR, It works with all AHD cameras, More Clearer.

  • 4 Channel 1080P AHD real-time recording (1080p/720P for selection)

  • Support video searching function so that we can easily get files of a certain period.

  • Support real-time playback, as well as review the video on computer

  • Support remote control and mouse operation.

  • Recording video can be overlaid with date/ time, plate number etc.

  • Optional file packing time to meet your real requirement.

  • Support wide range of voltage input from 12V to 32V.

  • Support real time monitor from phone and PC.

  • Support WIFI remote monitor,

  • Support 2 SD card, and (128G*2)

  • Support auto recording , manually recording , alarm recording , fire off recording.

  • Delayed video recording functions when vehicle is shut down (time settings can be up to 24 hours)

  • Support 8CH alarming inputs and 1CH independent alarm output (open/close door, brake, back up, motion detection etc).

  • Support upgrade via SD card or USB slot.

  • Video playback, speed and GPS track playback.

  • Built in GPS Module, Record GPS track and speed.

  • Eight channel 4pin connector video and audio input, one channel AV connector video and audio output.

  • SD card design for storage, more convenient and vibration-proof than hard disk version.


hd high definition vehicle blackbox dvr

mobile vehicle dvr

sd card for vehicle blackbox dvr

dvr vehicle blackbox

car dvr vehicle camera

Vehicle Blackbox Camera DVR Specification

Item

Detailed Specification

Appearance structure

Size: 145×58×193mm

Shell material: PC+ABS, body material: aluminum alloy

Protection grade

IP54

Environmental suitability

Operating temperature: -30℃70℃,

Storage temperature: -40℃85℃

Working voltage

Working voltage range: 9 - 32V

Support car battery protection: 8.5V±0.5V/12V system, 17V±0.5V/24V system

12V/24V adaptive36V system is not supported

Ultra-low power consumption design

Static current <2mA

Support zero- power-consumption sleep mode

Power consumption

Average power consumption is less than 30W

Super capacitor

3 super capacitors can supply power to the system and camera

2~3s to save the complete video before power failure

Indicator lights

lights (1 positioning signal, 1 communication signal, 1 video recording, 1 terminal operation indication)

External interface

Power supply: TE-1318384-2

Positioning antenna connector: Fakra-C blue

Communication antenna connector: Fakra-D

Video interface: M12-4

IPC interface: M12-6

Video

Maximum 6 channels of AHD/CVBS video input, can supply power to the camera, the output voltage value is 12V, single channel maximum output current 0.5A

1-channel IPC video input connector, 12V power supply

1-channel CVBS output

Audio

2-way camera recording, recording line supports key input detection

1 way shout MIC input

Storage

2.5-inch mechanical / solid state hard disk, can support 7mm / 9.5mm, hard disk shock absorption device fixed in the terminal (Maximum capacity support 2TB)

2 SD cards, pluggable mode, does not support simultaneous recording (Maximum capacity support 512GB)

Data interface

2-way RS232 interface, 5V power supply @ 500mA

1-way 485 interface, 1 way IPC interface, 12V power output (1A)

Positioning module

GPS and BeiDou positioning module

Communication module

4G module

SIM card

Drawer plug-in SIM card

IO function

8-channel input: ACC, left steering, right steering, door edge, emergency, reverse, brake, speed pulse

1 way output: fuel break power


Vehicle DVR Camera Q&A

What are DVR and CCTV?

A DVR converts analog camera signals into digital format and stores them on a hard disk. DVR and CCTV are storage methods for closed-circuit television security systems.

What is the difference between DVR and NVR?

A DVR converts analog material to digital, while an NVR is only suitable for digital material.

What is the difference between a dash cam and an MDVR?

An MDVR is a complete monitoring system with more functions than a driving recorder, such as sensors, in-car screens, etc.

What is the role of a car DVR?

A car DVR provides functions such as 24-hour monitoring, audio and video recording, transmission, positioning, etc.

How many camera connections does MDVR support?

The number of camera connections for MDVR depends on the specific model and configuration. Generally speaking, MDVR can support 2 to 8 L or even more camera connections

Can MDVR's video be accessed remotely?

Yes, yuweitek's MDVR supports remote access. You can connect to the MDVR through the background, and remotely view real-time video, playback video, and adjust settings.
