1080p Car DVR Camera
1080p Car DVR
YUWEI, a Chinese manufacturer, offers high-quality and affordable 1080p car DVR cameras, supporting ADAS and DMS assistance systems, as well as 1080P video recording. We welcome your inquiries and purchases.
1080p Car DVR Features:
- Built-in HiSilicon high-performance image processing chip, H.264 encoding, high compression ratio, clear images
- Supports 4-channel digital HD/analog SD video and audio input, 1-channel video and audio synchronous output, 1-channel VGA output
- Supports 4-channel 1080P real-time local recording
- Supports 4-channel 720P real-time local recording
- Supports 4-channel 960H real-time local recording
- Professional vehicle power supply with 8-36V DC wide voltage input design
- Multiple protection circuits, including under-voltage, short-circuit, and reverse polarity, suitable for various vehicle types
- Supports intelligent power management identification, automatic shutdown at low battery, low power consumption when engine is off
- Special file management mechanism for data encryption to ensure data security
- Proprietary bad sector detection technology to ensure recording continuity and extend disk life
- Built-in super capacitor to avoid data loss and disk damage due to unexpected power-off
- Supports 2.5-inch hard drive, with a maximum capacity of 4TB
- Supports SD storage, with a maximum of two 256GB cards
- Supports GPS/BD positioning with high sensitivity and fast positioning
- Supports Wi-Fi wireless download, supporting 802.11b/g/n, frequency 2.4GHz
- Built-in 3G/4G module, supports LTE/HSUPA/HSDPA/WCDMA/EVDO
1080p Car DVR Technical Specifications:
System:
- Main Processor: Hi3520DV300
- Operating System: Embedded Linux OS
- Language: Chinese/English/Traditional
- Operating Interface: Graphical menu interface, supports mouse operation
- Password Security: Two-level management with user and administrator passwords
Audio/Video:
- Video Standard: PAL/NTSC
- Compression Standard: H.264
- Image Resolution: 1080P/720P/960H/D1/CIF
- Playback Quality: 1080P/720P/960H/D1/CIF
- Combination Method: Multiple options
- Decoding Capability: 1 channel 1080P real-time
- Recording Quality: 1 to 6 levels available
- Screen Display: Supports 1, 2, 3, or 4 screen display
- Audio Compression: G.726
- Recording Method: Synchronized audio and video recording
Recording & Playback:
- Recording Method: Manual, alarm-triggered
- Video Bitrate: Full frame 4096Mbps, 6 quality levels selectable
- Audio Bitrate: 8KB/s
- Storage Medium: Hard disk + SD card
- Video Query: Search by channel, video type, or alarm type
- Local Playback: Single channel, by time
Software Upgrade:
- Upgrade Mode: Manual upgrade, auto upgrade, remote upgrade, emergency recovery
- Upgrade Method: USB interface, wireless network, SD card, hard disk
Interfaces:
- Audio/Video Input: 4 channels, 6-pin aviation connector (built-in switch)
- Audio/Video Output: 1 VGA video output, 1 aviation connector for audio/video output
- Alarm Input: 4 digital inputs (configurable for positive/negative trigger)
- Disk Interface: 2.5-inch hard disk, supports up to 2TB
- SD Card: 2 SDXC high-speed cards (supports up to 256GB)
- USB Interface: 1 USB 2.0 (supports full mouse operation, USB self-check)
- Ignition Input: 1 ACC signal
- Serial Port: 1 RS485
- HDMI: 1
- LED Indicators: PWR/REC/4G/GPS
- Disk Lock: 1
Extended Features:
- GPS: Supports antenna insertion/removal/short-circuit detection
- 2G/3G/4G: Supports CDMA/EVDO/GPRS/WCDMA/FDD LTE/TDD LTE
- Wi-Fi: 802.11b/g/n, frequency 2.4GHz
Other:
- Power Input: DC: 8V ~ 36V
- Power Consumption: Standby 3mA, Max power 30W @12V 2.5A @24V 1.25A
- Operating Temperature: -20°C to 70°C
- Storage Capacity:
- 1080P: 1.2GB/hour/channel
- 720P: 1GB/hour/channel
- 960H: 750MB/hour/channel
The 1080p Car DVR Camera F6 is suitable for trucks, buses, school buses, mining vehicles, and other fleets. Please feel free to contact us for detailed solutions.
