Cloud Storage Dash Cam
Cloud Storage Dash Cameras
Cloud Storage Dash Cam is an LTE dashcam system designed specifically for commercial vehicles. It supports cloud storage of videos. This feature-rich camera system can simultaneously record 4/5 independent channels and provides valuable ADAS (Advanced Driver Assistance Systems) and DMS (Driver Monitoring Systems) algorithms, actively assisting drivers in enhancing road awareness and safety by providing real-time, actionable alerts. Video clips triggered by critical events or the cabin SOS button are saved to the cloud server for later viewing or evidence support. Additional features of this system, including support for peripheral sensors, WiFi connectivity, and expanded device storage, make the V5 series the perfect solution for various applications across multiple industries.
Features of Cloud Storage Dash Cam:
Real-time video visibility for up to 5 channels
The V5 comes with 1 built-in camera (default 720P, also available in 1080P upon request) and supports up to 4 remote cameras (optional), monitoring the vehicle's exterior, cabin, sides, rear, or driver regardless of the vehicle's status, whether it's in motion or parked. Some cameras can even issue alerts, notifying drivers or passengers of any potential risks.
Driver Guidance/Assistance
Driver Fatigue/Distraction Monitoring (DMS)
DMS cameras (optional) can track the driver's facial expressions to monitor their attention and issue warnings through in-cabin alerts when necessary.
Advanced Driver Assistance Systems (ADAS)
Key Videos to the Cloud
Worried about important video clips regarding collisions or other events being overwritten by loop recording, or accidentally or intentionally deleted from your device? No worries. These data will remain unaffected by loop recording and will be uploaded to the platform for storage. If any disputes arise in the near future, they can serve as evidence support.
Expandable Storage for More Data
The host of the V5 camera system has 2 microSD slots, supporting up to 512 GB of device storage. This allows you to store more data than expected, fully meeting the data demands of long-distance transportation.
One Platform to Meet All Your Operational Needs
As an operator, you can check real-time information about fleet location, surrounding environment, alerts, and other details through our dedicated platform IVMS anytime, anywhere. Note: You can also use your own platform. We will assist you in the interoperability process.
Specifications of Cloud Storage Dash Cam
Parameter classification | Parameter item | Details |
Basic parameters | Appearance | device integrate with ADAS cam |
Product Type | 4G DVR Car Video Terminal | |
network standard | 4G Global Band | |
Memory | 256MB(Flash)+1GB(DDR) | |
Front camera | 1080P, MIPI Camera, H:112°V:55° | |
In-car camera | AHD 720P, with light sensor/infrared night vision, | |
AHD Camera, single pass, infrared night vision, H=60° V=42° | ||
4th Channel camera | AHD 720P | |
Hardware function
| GPS | Support: GPS+BDS |
Wi-Fi | 802.11b/g/n | |
trumpet | 8 ohms 1.5 watts, 1 channel, with sound cavity | |
MIC | Built-in dual silicon microphone design | |
Accelerometer | 3-axis accelerometer | |
Interface | micro 5Pin USB | USB×1, data interface |
BMW connector | Power+/GND ACC Left turning signal cable Right turning signal cable SOS Cable (Panic button) | |
RS232 | 1*RS232 | |
SIM card holder | Micro SIM | |
TF card holder | TF×2 (Card 1 and Card 2 support circular storage) | |
Power supply | Power supply | 12V/24V power supply |
Button& Indicator light
| Reset button | Long press the power button for 8 seconds to reset |
indicator light | 2-color indicator | |
Alarm key | Standard emergency alarm connector | |
Antenna
| GPS Antenna | Built-in ceramic antenna |
4G antenna | Built-in FPC+IPEX transposon | |
WIFI antenna | Built-in FPC+IPEX transposon | |
Memory card | 4G～2TB, patented DXR streaming storage format | |
Electrical Specification | Operating temp. | -20℃～70℃ |
Storage temp. | -40℃～85℃ | |
Static Protection | 6KV contact, 10KV air | |
Vibration test | Car vibration | |
Current consumption | When the working voltage is 12V, the current is from 500mA to 1A (depending on whether the algorithm is turned on, etc.) When ACC OFF: ≤3mA | |
Other quality requirements | According to JT/T794 standard (including hard test, soft test, reliability, quality, etc.) | |
