Rear View Mirror Dash Cam and Reversing Cameras


Due to the highly concentrated operation required by drivers of vehicle mechanical equipment, there is a high risk of safety hazards and resulting economic losses when they are unable to focus on the screen of the onboard rearview display or lack reverse radar warnings. YUWEI's solution for fleet vehicles addresses this issue by installing rear view mirror dash cams and reversing cameras, enabling real-time monitoring of the vehicle's surroundings. The AI-based onboard monitoring system not only eliminates the need for reverse radar installation and complex wiring procedures but also detects personnel and vehicles in the work area in real-time, providing visual and auditory alerts to enhance operational efficiency, mitigate safety hazards, and prevent economic losses.



Rear View Mirror Dash Cam and Reversing Cameras


Product Features

- Video Monitoring: Capture real-time footage of the vehicle's surroundings and transmit it to the processor for further processing.

- Intelligent Detection: Precisely identify and track pedestrians and non-motorized vehicles in the left, right, and rear views.

- Warning Alerts: Automatically alert the driver when pedestrians or non-motorized vehicles are detected, assisting the driver in making accurate judgments.

- Multiple Alert Options: The display includes a built-in microphone and supports external audiovisual alarm devices, overlaying warning indicator frames to adapt to different application scenarios.

- Waterproof Wide-angle Cameras: IP69K waterproof rating, multiple selectable angles providing a broader field of view, reducing blind spots, and ensuring normal operation in various adverse weather conditions.



Product Specifications

- Color LCD Car Display: 9-inch IPS screen

- Recording Operating System: Android/Linux

- Recording Resolution: 1280 X 720P

- Recording Audio Input: Built-in microphone

- Pedestrian/Vehicle Detection: Alerts for pedestrians and non-motorized vehicles approaching the area in the left, right, and rear views

- Alarm Area Calibration: Customizable alert area settings

- Display Modes: Supports single-screen/four-screen display

- Video Signal Input: Supports 4-channel AHD 720P video signal input

- Storage Capacity: External TF card (supports up to 256GB)

- Video Format: H.264 TS format

- Operating Temperature: -20℃~+70℃

- Storage Temperature: -30℃~+80℃

- Operating Voltage: DC11-32V



Dash Camera

- AHD 720P High Definition Vehicle Waterproof Camera

- Effective Pixels: 1280(H) X 960(V)

- Minimum Illumination: 0LUX (with built-in infrared light enabled)

- IR-CUT: Automatically switches between day and night modes

- Waterproof Rating: IP69K

- Operating Temperature: -20℃~+60℃

- Storage Temperature: -30℃~+70℃

- Operating Voltage: DC12V


Rear Camera Q&A

What are the features of Rear View Cameras?

Waterproof, night vision, G-Sensor, 3D imaging, split screen, built-in GPS, built-in GSM, parking lines, ADAS, voice interaction, 5G SIM card. Contact us for more OEM details.

What other products do you offer besides Rear View Cameras?

Parking sensors, parking assist systems, reverse cameras, monitors, reverse radars, license plate cameras, wireless rearview cameras. Please contact us for more OEM details.

Which fleets are Rear View Cameras suitable for?

Buses/trucks/trailers/heavy vehicles

Which languages does the Rear View Cameras support in the backend?

The system supports multiple language settings such as Chinese, English, Korean, Japanese, etc., suitable for more countries and regions.

Why choose China YUWEI?

We are the source factory with over 25 years of experience in the industry of 360-degree car cameras and rearview cameras. Our products, such as reverse cameras, 360-degree onboard cameras, and GPS-enabled dash cams, have the highest market share in China. Compatible with 99.9% of vehicle models, allowing older vehicles to enjoy cutting-edge technology in safety and affordability. We cooperate with over 50 car dealerships (Dongfeng, BYD, etc.) and 5000+ automobile showrooms (4S stores). Optional top-notch precision cameras.
