Rear View Mirror Dash Cam and Reversing Camera

Rear View Mirror Dash Cam and Reversing Cameras

Due to the highly concentrated operation required by drivers of vehicle mechanical equipment, there is a high risk of safety hazards and resulting economic losses when they are unable to focus on the screen of the onboard rearview display or lack reverse radar warnings. YUWEI's solution for fleet vehicles addresses this issue by installing rear view mirror dash cams and reversing cameras, enabling real-time monitoring of the vehicle's surroundings. The AI-based onboard monitoring system not only eliminates the need for reverse radar installation and complex wiring procedures but also detects personnel and vehicles in the work area in real-time, providing visual and auditory alerts to enhance operational efficiency, mitigate safety hazards, and prevent economic losses.

Product Features

- Video Monitoring: Capture real-time footage of the vehicle's surroundings and transmit it to the processor for further processing.

- Intelligent Detection: Precisely identify and track pedestrians and non-motorized vehicles in the left, right, and rear views.

- Warning Alerts: Automatically alert the driver when pedestrians or non-motorized vehicles are detected, assisting the driver in making accurate judgments.

- Multiple Alert Options: The display includes a built-in microphone and supports external audiovisual alarm devices, overlaying warning indicator frames to adapt to different application scenarios.

- Waterproof Wide-angle Cameras: IP69K waterproof rating, multiple selectable angles providing a broader field of view, reducing blind spots, and ensuring normal operation in various adverse weather conditions.

Product Specifications

- Color LCD Car Display: 9-inch IPS screen

- Recording Operating System: Android/Linux

- Recording Resolution: 1280 X 720P

- Recording Audio Input: Built-in microphone

- Pedestrian/Vehicle Detection: Alerts for pedestrians and non-motorized vehicles approaching the area in the left, right, and rear views

- Alarm Area Calibration: Customizable alert area settings

- Display Modes: Supports single-screen/four-screen display

- Video Signal Input: Supports 4-channel AHD 720P video signal input

- Storage Capacity: External TF card (supports up to 256GB)

- Video Format: H.264 TS format

- Operating Temperature: -20℃~+70℃

- Storage Temperature: -30℃~+80℃

- Operating Voltage: DC11-32V

Dash Camera

- AHD 720P High Definition Vehicle Waterproof Camera

- Effective Pixels: 1280(H) X 960(V)

- Minimum Illumination: 0LUX (with built-in infrared light enabled)

- IR-CUT: Automatically switches between day and night modes

- Waterproof Rating: IP69K

- Operating Temperature: -20℃~+60℃

- Storage Temperature: -30℃~+70℃

- Operating Voltage: DC12V
