YUWEI AD PLUS Dash Cam
YUWEI AD PLUS Dash Cam is an advanced AI dash cam with 4G/WiFi communication capabilities, supporting remote video monitoring, designed primarily for fleet tracking and management.
In addition, it features front and rear cameras, supporting up to 4 camera channels for real-time audio and video recording, and dual TF card storage. Global 4G network connectivity enables real-time video transmission, while GPS/BDS positioning ensures precise tracking.
It also integrates advanced driver assistance systems (ADAS, DSM) to enhance safety. Widely used in the fields of trucks, ride-hailing vehicles, taxis, logistics, and government vehicles, among others.
Parameter classification | Parameter item | Details | Remark |
Basic parameters | Appearance | device integrate with ADAS cam | |
Product Type | 4G DVR Car Video Terminal | ||
network standard | 4G Global Band | ||
Memory | 256MB(Flash)+1GB(DDR) | ||
Front camera (ADAS Camera) | 1080P, MIPI Camera, H:112°V:55° | ||
In-car camera | AHD 720P, with light sensor/infrared night vision, | ||
AHD Camera, single pass, infrared night vision, H=60° V=42° | |||
4th Channel camera | AHD 720P | ||
Hardware function
| GPS | Support: GPS+BDS | |
Wi-Fi | 802.11b/g/n | ||
trumpet | 8 ohms 1.5 watts, 1 channel, with sound cavity | ||
MIC | Built-in dual silicon microphone design | ||
Accelerometer | 3-axis accelerometer | ||
Interface | micro 5Pin USB | USB×1, data interface | |
BMW connector | Power+/GND ACC Left turning signal cable Right turning signal cable SOS Cable (Panic button) | ||
RS232 | 1*RS232 | ||
SIM card holder | Micro SIM | ||
TF card holder | TF×2 (Card 1 and Card 2 support circular storage) | ||
Power supply | Power supply | 12V/24V power supply | |
Button& Indicator light
| Reset button | Long press the power button for 8 seconds to reset | |
indicator light | 2-color indicator | ||
Alarm key | Standard emergency alarm connector | ||
Antenna
| GPS Antenna | Built-in ceramic antenna | |
4G antenna | Built-in FPC+IPEX transposon | ||
WIFI antenna | Built-in FPC+IPEX transposon | ||
Memory card | 4G～2TB, patented DXR streaming storage format | ||
Electrical Specification | Operating temp. | -20℃～70℃ | |
Storage temp. | -40℃～85℃ | ||
Static Protection | 6KV contact, 10KV air | ||
Vibration test | Car vibration | ||
Current consumption | When the working voltage is 12V, the current is from 500mA to 1A (depending on whether the algorithm is turned on, etc.) When ACC OFF: ≤3mA | ||
Other quality requirements | According to JT/T794 standard (including hard test, soft test, reliability, quality, etc.) | ||
