Side view of camera

Auto side view camera 1080p IP67 Waterproof

Date Time: April 09, 2024
Reading volume: 127
Author: YUWEI

Side view of camera


YUWEI offers the finest auto side view camera featuring 1080P resolution, IP69K waterproof rating, and night vision capability. Designed primarily to monitor the blind spots on the right side of vehicles, this camera streams real-time imagery to the algorithmic host, identifying pedestrians in blind spots and issuing collision warnings in hazardous areas. It provides both in-car intelligent prompts and external audio. The optical alarm system delivers bidirectional hazard alerts to drivers and pedestrians, significantly reducing the incidence of traffic accidents.

side view of camera

Features of the side view camera:

- 1/2.9" CMOS image sensor, 2 million pixels

- Wide viewing angle range: 148° horizontally and 78° vertically

- Automatic white balance, exposure, and image enhancement

- Supports 3D noise reduction

- IP67 waterproof rating

- Aviation connector for stability and reliability

- Shell IK10 anti-collision rating

- Adjustable lens angle of view

- Elegant metal alloy shell design

- 650/850 two-pass filter



Specifications of the side view camera:


Image Sensor

1/ 2.9' CMOS , 2.0 million pixels

Effective Pixels

1280( H )×720(   V )

video standards

AHD ,   720p

Video format

PAL

Frame rate

25fps , 1280× 72 0

day and night mode

IR -CUT,   color during the day, black and white at night

light

4 850   infrared LEDs

electronic shutter

AUTO   1/50 (1/60) ~ 1/100,000sec

lens

2.3mm fixed   focus HD lens

Viewing range

Horizontal   148° Vertical 78°

Audio

none

Operating Voltage

DC12V

Working current

180 mA @DC12V

Enclosure rating

Metal,   black, IP67

weight

180g

size

52.7mm×36.5mm×56.3mm

working temperature

- 30 ℃ ~ 70 ℃

storage temperature

-40 ℃ ~85 ℃

Interface   definition
