Car Camera with GPS Tracker Supplier


Provides GPS online vehicle tracking and live video recording through a mobile app. This is a dual-camera device (front and rear), with the front camera featuring FULL HD 1920x1080px resolution and supporting 3G WiFi. Images are stored on a micro SD card. The camera body is made from high-quality materials, making it resistant to high temperatures and extreme cold.



Car Camera with GPS TRACKER


Fleet Management Software:

No software installation is required. Access everything via a web browser on a desktop, laptop, tablet, or smartphone through the Internet. Basic functions include tracking vehicles, whether cars or trucks. If the vehicle is online, you will see its current location on the map and can continue tracking its route. If offline, its last known location will be displayed.



Features of Car Camera with GPS Tracker:

- Ultra HD Real-Time Recording: 1920*1080P FULL HD camera starts recording immediately upon powering on.

- WiFi Connection: WIFI module connects to the mobile app for real-time preview and video file downloads.

- Parking Auto Photography: When ACC is off or power is cut, the camera records with a 5-minute delay and automatically saves video after power loss.

- Collision Auto Recording/Locking: Automatically records and locks emergency footage in the event of a collision, generating a fixed emergency video file.

- 140° Ultra-Wide Angle: True 140° clear wide-angle for a broader field of view, covering up to three lanes effortlessly.

- Vehicle Security Features: Built-in high-precision GPS module for remote real-time location monitoring, driving trajectory playback, collision notifications, and speed alerts.

- Large Memory: Supports up to 128GB TF card, storing up to 16 hours of real-time video.

- Maintenance/Insurance Reminders: App platform includes car maintenance/insurance reminder system, notifying you before maintenance or insurance expiration.



Specifications of Car Camera with GPS Tracker:



Parameter classification

Parameter item

Details

Remark

Basic parameters

Appearance

device integrate with ADAS cam


Product Type

4G DVR Car Video Terminal


network standard

4G Global Band


Memory

256MB(Flash)+1GB(DDR)


Front camera

(ADAS Camera)

1080P, MIPI Camera, H:112°V:55°


In-car camera

AHD 720P, with light sensor/infrared night vision,


DSM camera

AHD Camera, single pass, infrared night vision, H=60° V=42°


4th Channel camera

AHD 720P


Hardware function









GPS

Support: GPS+BDS


Wi-Fi

802.11b/g/n


trumpet

8 ohms 1.5 watts, 1 channel, with sound cavity


MIC

Built-in dual silicon microphone design


Accelerometer

3-axis accelerometer


Interface

micro 5Pin USB

USB×1, data interface


BMW connector

Power+/GND

ACC

Left turning signal cable

Right turning signal cable

SOS Cable (Panic button)


RS232

1*RS232


SIM card holder

Micro SIM


TF card holder

TF×2 (Card 1 and Card 2 support circular storage)


Power supply

Power supply

12V/24V power supply


Button&

Indicator light



Reset button

Long press the power button for 8 seconds to reset


indicator light

2-color indicator


Alarm key

Standard emergency alarm connector




Antenna



GPS Antenna

Built-in ceramic antenna


4G antenna

Built-in FPC+IPEX transposon


WIFI antenna

Built-in FPC+IPEX transposon


Memory card

4G~2TB, patented DXR streaming storage format


Electrical Specification

Operating temp.

-20℃~70℃


Storage temp.

-40℃~85℃


Static Protection

6KV contact, 10KV air


Vibration test

Car vibration


Current consumption

When the working voltage is 12V, the current is from 500mA to 1A (depending on whether the algorithm is turned on, etc.)

When ACC OFF: ≤3mA


Other quality requirements

According to JT/T794 standard (including hard test, soft test, reliability, quality, etc.)


Product specification pictures:

Car Camera with GPS Tracker Supplier

Car Camera with GPS Tracker Manufacturer

l Red light

Equipment situation

Light status

Before the program is ready

Solid on

during upgrade

On for 1 second, off for 4 seconds

update completed

camera lost

On for 0.1 seconds, off for 0.1 seconds, flashing 4 times at a time, flashing once every 4 seconds

SIM card missed

On for 1 second, off for 1 second

other status

Always off



l Green light

Equipment situation

light status

Before the program is ready

Solid on

during upgrade

On for 1 second, off for 4 seconds

update completed

The card is recording normally

On for 1 second, off for 1 second

Unrecorded card abnormal

On for 0.1 seconds, off for 0.1 seconds, flashing 4 times at a time, flashing once every 4 seconds

other status

Always bright

TF card/SIM card/USB location

Car Camera with GPS


China is the manufacturer of the car camera with GPS tracker, with the factory located in Dongguan, China. Products are certified by FCC (USA), CE (EU), and E-mark, among others. Welcome to request a quote.
