YUWEI Fleet Dash Cam System


YUWEI Fleet Dash Cam with GPS Tracking System, which can exonerate drivers and help you operate a safer and more efficient fleet.


1. Driver Video Recording: Immediately view accident footage after an incident occurs, which can be used as evidence in conflicting reports of road incidents.


2. GPS/BDS Data/Reports: In addition to videos, our Fleet Dash Cam system also features GPS data reports, speed/brake alerts, and geofencing functionality.


3. Enhanced Driver Safety: By visually confirming whether the driver is wearing a seatbelt and focusing on the road, it reduces the risks associated with motor vehicles.


YUWEI AI Fleet Dash Cam supports 1080p video monitoring and recording, equipped with a GPS tracker, designed to be tamper-proof, and comes standard with LTE connectivity, night vision, front/driver's side view, unlimited video storage via cloud connection, and audio recording capabilities.

Fleet dash cam system


Fleet Dash Cam System helps you preserve evidence


Did you know that 81% of commercial truck-related accidents are caused by driver error? However, truck drivers often bear the responsibility for damages! If you are found at fault, an average lawsuit resulting from a car accident could cost your fleet up to $100,000. Having video evidence of the incident can help protect your business from injury claims and other threats, such as:


1. Insurance fraud/staged accidents

2. False or exaggerated claims

3. Lack of witnesses/disoriented drivers

4. Conflicting reports of actual events

5. Expensive and increasing insurance premiums

6. Poor driving habits or behavior

Benefits of the Fleet Dash Cam System


  • Lower Fleet Management Costs: Managing a fleet incurs various expenses, including vehicle insurance, leasing fees, damage costs, and maintenance fees. These costs may account for more than two-thirds of the overall fleet operation costs. However, by utilizing our Dash Cam system with centralized data and predictive reporting, you can proactively minimize these sometimes necessary expenses.


  • Improved Fleet Safety: Access to real-time data and video clips allows you to identify fleet safety issues proactively. From drivers engaging in dangerous driving behaviors to vehicle maintenance and mileage consumption, Yuwei's Fleet Dash Cam system enables you to address common fleet issues before they become significant problems. Our Dash Cam system can capture videos from multiple angles instantly, providing immediate insights and eliminating driver misconduct. By leveraging comprehensive datasets, you can also track cost-saving trends and reduce expenditures.


  • Reduced Accident Costs: Truck Dash Cams can significantly reduce costs associated with accidents and provide crucial video evidence showing your drivers were not at fault. Yuwei's Dash Cam can be used for litigation claims, showcasing what occurred before, during, and after an accident, including detailed GPS data such as vehicle speed.


Yuwei AI Dash Cam systems can meet the specific requirements of your industry. We offer services to fleets using Dash Cams to record footage in original 720p/1080p quality. All cameras are equipped with front and driver's side views, including night vision capabilities.

Fleet Dash Cam System Specification


Parameter classification

Parameter item

Details

Basic parameters

Appearance

device integrate with ADAS cam

Product Type

4G DVR Car Video Terminal

network standard

4G Global Band

Memory

256MB(Flash)+1GB(DDR)

Front camera

(ADAS Camera)

1080P, MIPI Camera, H:112°V:55°

In-car camera

AHD 720P, with light sensor/infrared night vision,

DSM camera

AHD Camera, single pass, infrared night vision, H=60° V=42°

4th Channel camera

AHD 720P

Hardware function









GPS

Support: GPS+BDS

Wi-Fi

802.11b/g/n

trumpet

8 ohms 1.5 watts, 1 channel, with sound cavity

MIC

Built-in dual silicon microphone design

Accelerometer

3-axis accelerometer

Interface

micro 5Pin USB

USB×1, data interface

BMW connector

Power+/GND

ACC

Left turning signal cable

Right turning signal cable

SOS Cable (Panic button)

RS232

1*RS232

SIM card holder

Micro SIM

TF card holder

TF×2 (Card 1 and Card 2 support circular storage)

Power supply

Power supply

12V/24V power supply

Button&

Indicator light



Reset button

Long press the power button for 8 seconds to reset

indicator light

2-color indicator

Alarm key

Standard emergency alarm connector



Antenna



GPS Antenna

Built-in ceramic antenna

4G antenna

Built-in FPC+IPEX transposon

WIFI antenna

Built-in FPC+IPEX transposon

Memory card

4G~2TB, patented DXR streaming storage format

Electrical Specification

Operating temp.

-20℃~70℃

Storage temp.

-40℃~85℃

Static Protection

6KV contact, 10KV air

Vibration test

Car vibration

Current consumption

When the working voltage is 12V, the current is from 500mA to 1A (depending on whether the algorithm is turned on, etc.)

When ACC OFF: ≤3mA

Other quality requirements

According to JT/T794 standard (including hard test, soft test, reliability, quality, etc.)

Product specification pictures:

YUWEI Fleet Dash Cam System

Table of Contents

YUWEI Fleet Dash Cam System
Fleet Dash Cam System helps you preserve evidence
Benefits of the Fleet Dash Cam System
Fleet Dash Cam System Specification

Why are Dash Cams important for commercial fleets?

There are several reasons why a fleet dash cam system is crucial for commercial fleets.

They can help:

• Use video evidence to prevent fraudulent claims and prove the driver's innocence, saving money for commercial businesses

• Provide 360-degree operational visibility through cabin and exterior cameras

• Identify poor driving events to offer personalized driver coaching and increase driver engagement

• Reduce the number of accidents by sending real-time alerts to drivers when they deviate from their lane or drive too close to other vehicles to prevent collisions

• Use artificial intelligence to understand driver behaviors such as phone usage, smoking, eating, or fatigued driving

How long do recorded videos last on a Dash Cam?

This depends on the different fleet solutions offered by Yuwei, but memory can be added and adjusted according to customer needs. Please consult with our market partners for fleet camera specifications.


Email:hello@yuweitek.com

Does your Fleet Dash Cam come with built-in GPS tracking?

Yes, our Fleet Dash Cam comes with a complete set of GPS tracking reports for vehicle management.

Can the Fleet Dash Cam detect distracted driving?

Yes, Yuwei AI Dash Cam can detect distractions such as texting while driving, smoking while driving, eating/drinking while driving, seat belt detection, and fatigue driving.
