Full HD vs 1080 Dash Camera
Full HD 1080 Dash Camera
YUWEI is a Chinese AI 4G dash camera supplier, offering Full HD vs. 1080p HD dash camera installations. If you have any needs, please feel free to consult our fleet engineers.
The YUWEI V5 is an intelligent dash camera designed to fit your vehicle. This compact and stylish model provides more windshield space and helps keep your focus on the road. With 1080p recording, you'll capture full high-definition video footage.
In essence, a 1080p dash camera can deliver "astonishing" video quality, which is the current "standard" for dash camera quality, a feature that our V5 model is equipped with.
Here are the specifications for our V5 dash cam:
Parameter classification | Parameter item | Details | Remark |
Basic parameters | Appearance | device integrate with ADAS cam | |
Product Type | 4G DVR Car Video Terminal | ||
network standard | 4G Global Band | ||
Memory | 256MB(Flash)+1GB(DDR) | ||
Front camera (ADAS Camera) | 1080P, MIPI Camera, H:112°V:55° | ||
In-car camera | AHD 720P, with light sensor/infrared night vision, | ||
AHD Camera, single pass, infrared night vision, H=60° V=42° | |||
4th Channel camera | AHD 720P | ||
Hardware function
| GPS | Support: GPS+BDS | |
Wi-Fi | 802.11b/g/n | ||
trumpet | 8 ohms 1.5 watts, 1 channel, with sound cavity | ||
MIC | Built-in dual silicon microphone design | ||
Accelerometer | 3-axis accelerometer | ||
Interface | micro 5Pin USB | USB×1, data interface | |
BMW connector | Power+/GND ACC Left turning signal cable Right turning signal cable SOS Cable (Panic button) | ||
RS232 | 1*RS232 | ||
SIM card holder | Micro SIM | ||
TF card holder | TF×2 (Card 1 and Card 2 support circular storage) | ||
Power supply | Power supply | 12V/24V power supply | |
Button& Indicator light
| Reset button | Long press the power button for 8 seconds to reset | |
indicator light | 2-color indicator | ||
Alarm key | Standard emergency alarm connector | ||
Antenna
| GPS Antenna | Built-in ceramic antenna | |
4G antenna | Built-in FPC+IPEX transposon | ||
WIFI antenna | Built-in FPC+IPEX transposon | ||
Memory card | 4G～2TB, patented DXR streaming storage format | ||
Electrical Specification | Operating temp. | -20℃～70℃ | |
Storage temp. | -40℃～85℃ | ||
Static Protection | 6KV contact, 10KV air | ||
Vibration test | Car vibration | ||
Current consumption | When the working voltage is 12V, the current is from 500mA to 1A (depending on whether the algorithm is turned on, etc.) When ACC OFF: ≤3mA | ||
Other quality requirements | According to JT/T794 standard (including hard test, soft test, reliability, quality, etc.) | ||
Product specification pictures:
l Red light
Equipment situation | Light status |
Before the program is ready | Solid on |
during upgrade | On for 1 second, off for 4 seconds |
update completed | |
camera lost | On for 0.1 seconds, off for 0.1 seconds, flashing 4 times at a time, flashing once every 4 seconds |
SIM card missed | On for 1 second, off for 1 second |
other status | Always off |
l Green light
Equipment situation | light status |
Before the program is ready | Solid on |
during upgrade | On for 1 second, off for 4 seconds |
update completed | |
The card is recording normally | On for 1 second, off for 1 second |
Unrecorded card abnormal | On for 0.1 seconds, off for 0.1 seconds, flashing 4 times at a time, flashing once every 4 seconds |
other status | Always bright |
TF card/SIM card/USB location
