What is DMS Camera?


DMS Camera for Driver Status Monitoring seamlessly integrates with the  YUWEI Intelligent MDVR System, providing a comprehensive solution to detect and address driving-related issues such as fatigue, distraction, and other misbehaviors. This advanced camera system prioritizes driving safety by alerting drivers in real-time.

dms cameras

Email:hello@yuweitek.com

DMS Camera Features


1.Driver Status Detection:

The camera interfaces with MDVR, actively monitoring driver behaviors.


Real-time alerts are triggered for fatigue, distraction, or any driving misbehavior detected.


2.Convenient Installation:

Hassle-free installation without the need for drilling holes.


Significantly reduces costs and labor associated with the installation process.


3.Wide Dynamic Range (WDR):

The camera boasts a wide dynamic range suitable for various lighting environments.


Ensures high-quality images and precise detection even when facing challenging light conditions, such as against sunlight or glare.

WDR Ensures Image Quality Even in Glaring Light


The DMS Camera's wide dynamic range guarantees exceptional image quality under diverse lighting conditions. Even when the camera is positioned against sunlight or glaring light, both image clarity and detection accuracy remain uncompromised.


Convenient Installation without Drilling Holes, Saving Cost and Labor:


With its user-friendly design, the camera can be effortlessly installed without the need for drilling holes. This not only simplifies the installation process but also leads to substantial savings in both cost and labor.

dsm camera Specification


Sensor Model:

1MCOMS

Sensor Size:

4-Jan

Pixel Size:

2.8um*2.8um

Effective Pixels:

1288*728

Focal Length:

3.91mm

Aperture:

F2.0

Depth of Field:

0.7m---∞

Focus Distance:

0.9

IR Filter:

940nm

Optical Angle of View (FOV - D/H/V):

75°/60°/42°

Distortion:

<-36%

Center Resolution:

>=500line

Operating Voltage:

5V-16V

Operating Current:

5V:150mA-220mA

Video Output:

AHD-720P

Video System:

PAL/NTSC

Product Dimensions:

78*85*50

Operating Temperature:

-20°----70°

Storage Temperature:

-30°----85°

Application


The DMS Camera for Driver Status Monitoring seamlessly integrates with the  YUWEI MDVR System, offering a professional and reliable fleet management solution for various vehicles, including trucks, taxis, and commercial vehicles. This comprehensive system ensures enhanced safety measures and improved monitoring capabilities for an efficient and secure transportation environment.


Opt for the DMS Camera and YUWEI MDVR System combination to elevate your fleet management strategy and prioritize the safety of your drivers and vehicles.
