Wireless Video System for Trucks
Wireless Video System for Trucks
YUWEI’s 2.4G 1080P HD wireless camera kit provides real-time monitoring for vehicles. It includes a high-definition camera and a 10-inch display screen, capable of showing live video without needing a network connection. The camera excels in low-light conditions and features an IP68 waterproof rating. Easy to install and compatible with various vehicles, this system enhances both safety and efficiency.
Features of the Wireless Video System for Trucks
High-Definition Imaging
Equipped with a high-resolution progressive scan CMOS sensor for clear, stable, and highly sensitive images.
Wireless Connectivity
Built-in 2.4G wireless module ensures stable, real-time video transmission without the need for internet access.
Night Vision
Infrared night vision capability allows for clear imaging even in low-light environments.
Noise Reduction
Adaptive 2D and 3D digital noise reduction technology ensures crisp and detailed images.
Durable Housing
Sturdy metal casing offers strong protection and easy installation on vehicles.
Waterproof Rating
IP68 rating ensures durability in harsh weather conditions, including rain and snow.
Specifications of the Wireless Video System for Trucks
In-Vehicle Monitoring Display
1. Screen Size: 10 inches
2. Operating Voltage: DC 9–32V
3. Screen Type: IPS 1024×600 HD display
4. Contrast Ratio: 500:1
5. Brightness: 500 cd/m²
6. Viewing Angle: Right/Left: 80°, Up/Down: 80°
7. Power Consumption: Max 6W
8. Supported Channels: CH1/CH2/CH3/CH4 (Quad view)
9. Aspect Ratio: 16:9
10. Reverse Polarity Protection: Yes
11. Storage: Supports SD card up to 256GB
12. Surge Protection: TVS protection
13. Supported Languages: Chinese, English, Finnish, French, Japanese, Korean, Italian, Spanish, Dutch, German, Russian, Traditional Chinese, Portuguese
14. Recording Function: Automatic recording when SD card is inserted
15. SD Card Formatting: Supported
16. Buttons: Power / Left / Menu / Right / Confirm / Channel Switch
17. Weight: 300g
Wireless Vehicle Camera
1. Transmission Power: 22 dBm (±1.5 dBm)
2. Transmission Distance: ≤300 meters
3. Operating Voltage: DC 9–36V
4. Polarity Protection: Yes
5. Sensor: 1/2.9" CMOS
6. Resolution: 1920×1080
7. Field of View: Horizontal: 108°, Vertical: 60°, Diagonal: 126°
8. Wireless Frequency: 2.4 GHz
9. Minimum Illumination: 0.1 LUX
10. Auxiliary Lighting: Infrared activates automatically in dark environments (switches display to black and white)
11. Waterproof Rating: IP68
12. Operating Temperature: -20°C to +70°C
13. Storage Temperature: -30°C to +80°C
14. Weight: 180g
Application Scenarios
This wireless monitoring system is suitable for a wide range of vehicles, including:
1. Trailers
2. Large and small rigid trucks
3. Buses
4. Construction vehicles
5. Sanitation vehicles
6. Agricultural machinery
7. Forklifts
